LED Outdoor luminaire ESKINA FRAME WL LED Wall luminaire, CCT switch, 3000/4000K, 1100/1200lm, IP65, anthracite

SLV


D
Product data sheet

You do not have the permission to see the prices

Shipping time: in stock

Product no.: 1004747
EAN: 4024163248976
In stock



Product Description:

The LED outdoor wall light ESKINA FRAME WL SINGLE CCT offers a modern lighting solution for outdoor areas. With a widely tiltable, round lamp head in a square housing, it provides an appealing look on the wall.

Technical Details:

The ESKINA FRAME WL SINGLE CCT has a beam angle of 95° and a power consumption of 15W. The light color can be set to warm white or neutral white using the rear DIP switch, allowing for flexible adaptation to the surroundings.

Accessories and Material:

The outdoor wall light comes with various accessories, such as dowels, Allen key, light color switch, screws, driver, and washers. The sturdy construction made of aluminum and glass ensures a long lifespan and protection against external influences.

Application Area:

Thanks to its high IP65 protection class and IK06 impact resistance class, the ESKINA FRAME WL SINGLE CCT is ideal for outdoor use, where it is protected against vandalism, moisture, and foreign objects. The wall light is also suitable for indoor use.

Installation and Possible Uses:

The outdoor wall light can be directly connected to 230V mains voltage and has a swivel range of 320°. With a light output of 73.33lm/W and a luminous flux of 1100lm at 3000K and 1200lm at 4000K, it provides bright and pleasant lighting.

Article number:
1004747
Purchasing quantity:
1 piece
Brand:
SLV
Prizes & Awards:
German Design Award 2022 winner
Energy efficiency category:
D
EPREL No:
916483
Product type:
outdoor wall luminaire
Energy consumption:
15 kWh/1.000 h
Manufacturer:
SLV
Operating voltage:
220-240 V~
Dimmable:
no
Lamp shape:
square
Power frequency:
50/60 Hz
Power consumption:
15 W
Emitting angle:
95 °
Bulbs in delivery:
yes
LED can be replaced :
replaceable by a specialist
Bulb type:
LED
Lamps/bulbs:
LED
Number of bulbs:
1
Voltage:
Clamp
Light colour:
warm white / neutral white (in steps)
Light emission:
direct
Beam direction:
swivelling
Light flux:
@ 3000K: 1100lm / @ 4000K: 1200 lm
Light yield:
73,33 lm/W
Nominal current:
350 mA
Colour temperature:
3000 / 4000 K
Average life span of a bulb in hours:
30000 h
Colour rendering index:
80 Ra
1B
Colour:
anthracite
Glass color:
prisma
Material:
aluminium
glass
Swivel range:
320 °
Throughwiring (installation of multiple luminaires in a row) is possible:
no
Dimension:
W∕ H∕ D: 11.5/7.3/18 cm
Weight:
1.36 kg
Field of application:
wall
Protection class:
1
IP-protection class:
IP65
Application area:
suitable for indoor use, suitable for outdoor use
Additional information:
System power: 15W
System power: 15W
Accessories:
dowel incl
allen key incl
light colour switch incl
Schrauben incl
driver incl
washers incl
ambient temperature:
-20°C ... +35°C
